Processor |
Processormodel | Motorola Coldfire V5x |
Netwerk |
Ethernet LAN | Ja |
Ondersteunde network protocollen (IPv4) | TCP/IP, IPv4, IPv6 |
Wi-Fi | Nee |
Certificaten |
Energy Star-certificaat | Ja |
Veiligheid | EN 60950-1+A11 (EU) IEC 60825-1+A1+A2 NRTL Listed (US/Canada) GS License (Europe) EN 60825-1+A1+A2 (Class 1 Laser/LED Device) GB4943-2001 Low Voltage Directive 2006/95/EC with CE Marking (Europe) other safety approvals as required by individual countries IEC 60950-1 (International) |
Technische details |
Kleur | Ja |
Maat | 21.5 " |
Maximale printafmetingen | 297 x 432 mm |
Non-ISO print papierafmetingen | executive,legal,letter |
Energie |
Typisch stroomverbruik | 440 W |
Stroomverbruik (in standby) | 30 W |
Stroomverbruik (indien uit) | 0.5 W |
Eisen aan de omgeving |
Relatieve luchtvochtigheid, in bedrijf | 10 - 80 procent |
Luchtvochtigheid bij opslag | 10 - 90 procent |
Temperatuur, in bedrijf | 10 - 30 °C |
Temperatuur bij opslag | 32 - 95 °C |
Bedrijfstemperatuur, bereik | 59 - 80.6 °F |
Gewicht en omvang |
Afmetingen (BxDxH) | 862 x 1066 x 370 mm |
Gewicht verpakking | 43000 g |
Afmetingen pallet (B x D x H) | 721 x 766 x 1961 mm |
Gewicht pallet | 195 kg |
Maximum afmetingen (B x D x H) | 862 x 1066 x 370 mm |
Gewicht | 40900 g |
Minimale systeemeisen |
Mac-compatibiliteit | Ja |
Protocollen |
Beheerprotocollen | SNMPv1, HTTP |
Overige specificaties |
Stroomvoorziening | 220 - 240 VAC (+/- 10%), 50 Hz (+/- 2 Hz), 6 A 115 - 127 VAC (+/- 10%), 60 Hz (+/- 2 Hz), 12 A |
Compatibele besturingssystemen | Mac OS X v 10.3, Mac OS X v 10.4 + Linux Windows 2000, Windows XP Home, Windows XP Professional, Windows Server 2003, Windows Vista, Windows XP Media Center, Windows XP Professional x64, Windows 7 (HP UPD) |
Netwerkfuncties | Fast Ethernet |
Gewicht | With print cartridges\n90.2 lb lbs |
Beveiligingsbeheer | Password-protected network embedded Web server enable/disable Network ports SNMPv1 community password change |
Afmetingen verpakking (BxDxH) | 718 x 702 x 478 mm |
Aantal per pallet | 4 stuk(s) |
Minimale systeemeisen | Windows XP-32 Home, Windows XP-32 Professional, Windows XP-x64 (print driver only): any Pentium II processor (Pentium III or higher recommended), 128 MB RAM, 250 MB hard disk space Windows 2000, Windows Server 2003 (print driver only): any Pentium II processor or higher, 64 MB RAM, 250 MB hard disk space SVGA 800 x 600 with 16-bit color display, Internet Explorer 5.5 or higher, CD-ROM drive, USB or Ethernet port Microsoft Windows 7 ready. For more information go to http:///go/windows7. Some features may not be available. Windows Vista (32-bit and 64-bit): 1 GHz processor, 512 MB RAM, 250 MB hard disk space |
Gewicht met verpakking | 95 lb lbs |
Afmetingen (std.) pallet (H x B x D) | 28.38 x 30.15 x 77.20 " |
Afmetingen verpakking (B x D x H) | 28.26 x 27.63 x 18.81 " |
Netwerkgereed | Ja |
Aanbevolen temperatuur bij gebruik | 15 - 27 °C |
Minimum systeemeisen voor Macintosh | Mac OS X v 10.3, 10.4, 10.5, 10.6 Power PC G3, G4, G5, or Intel Core processor 150 MB available hard disk space CD-ROM drive USB or Ethernet port |
Geluidskracht | 6.3 B(A) |
Afmetingen van het product wanneer het open is (LxBxD) | 34 " |
Printkwaliteit (kleur, presentatiekwaliteit) | 600 DPI |
Standaardinvoerladen | 2 |
Ingebouwde webserver | Ja |
Lettertypen | 84 scalable TrueType fonts |
Mediagewichten per papierpad | Tray 1: 60 to 220 g/m², Tray 2, automatic two-sided printing unit, optional Tray 3: up to 120 g/m² plain papers, up to 160 g/m² coated papers |
Envelopinvoer | Nee |
Opties voor dubbelzijdig printen | Manual (driver support provided) |
Papierverwerking | 100 sheet multi-purpose tray 250-sheet input tray, optional 500-sheet input tray 3 250-sheet face-down output bin |
Draadloze opties | Optional, enabled with purchase of a hardware accessory |
Driver-updates – omschrijving | Latest printer driver information available at http:///support |
Ondersteunde mediaformaten voor dubbelzijdig printen | A3 A4 A5 SRA3 B4 B5 |
Verwerking van uitvoer | Sheetfed |
Maximaal aantal papierladen | 3 |
Mediaformaten (lade 2) | A3 A4 A5 B4 B5 8k 16k Double postcard 148 x 182 to 297 x 432 mm |
Mediaformaten (lade 3) | A3 A4 B4 B5 8k 16k Double postcard 148 x 210 to 297 x 432 mm |
Mediatype en capaciteit, lade 2 | Sheets: 250 |
Mediatype en capaciteit, lade 3 | Sheets: 500 |
Mediagewicht lade 2 | Up to 120 g/m² plain papers, up to 160 g/m² coated papers |
Mediagewicht, lade 3 | Up to 120 g/m² plain papers, up to 160 g/m² coated papers |
Papierverwerking optioneel/invoer | Optional 500-sheet input tray 3 |
Papierverwerking standaard/invoer | 100 sheet multi-purpose tray 250-sheet input tray |
Papierverwerking standaard/uitvoer | 250-sheet face-down output bin |
Upgrademogelijkheden | Memory upgradeable to 448 MB optional 500 sheet tray only one additional tray may be added |
Papierverwerking optioneel/uitvoer | None |
Eerste pagina verschijnt, kleur (A4, standby) | As fast as 17 s |
Eerste pagina verschijnt, kleur (kwarto, standby) | As fast as 17 s |
Ondersteunde mediaformaten | Tray 1: Letter, legal, executive, 11x17, 12x18, 4x6, 5x8, 8.5x13, envelopes (No. 10, Monarch), custom: 3 x 5 to 12.6 x 18 in, Tray 2: letter, legal, executive, 11x17, 8.5x13, custom: 5.8 x 7.2 to 11.7 x 17 in, Optional tray 3: letter, legal, executive, 11x17, 8.5x13, custom: 5.8 x 8.3 to 11.7 x 17 in |
Akoestische emissie (gereed) | 5.3 B(A) |
Automatische papierherkenning | Nee |
SureSupply ondersteuning | Ja |
TEC (Typical Electricity Consumption) nummer | 1.787 kWh/Week |
Afmetingen, voetnoot (imperial) | Without trays and covers extended |
Aanbevolen mediagewicht (dubbelzijdig) | Up to 32 lb plain papers, up to 43 lb coated papers |
Standaard mediaformaten (dubbelzijdig, brits/amerikaans) | Letter legal executive 11 x 17 in 12 x 18 in |
Printkwaliteit (zwart, standaard) | 600 DPI |
Invoercapaciteit voor enveloppen (primaire lade) | 20 vel |
Printmarge onder (A4) | 4.23 mm |
Printmarge links (A4) | 4.23 mm |
Printmarge rechts (A4) | 4.23 mm |
Printmarge boven (A4) | 4.23 mm |
Printkwaliteit (zwart, beste kwaliteit) | 600 x 600 DPI |
Standaard uitvoercapaciteit voor enveloppen | 15 vel |
Geluidsdruk omstander (tijdens printen) | 49 dB(A) |
Eerste pagina verschijnt, monochroom (A4, standby) | As fast as 16 s |
Eerste pagina verschijnt, monochroom (kwarto, standby) | As fast as 16 s |
Bedieningspaneel | 16-character backlit display 5 buttons (Cancel job, Left arrow, Right arrow, Select, Back) 2 LED indicator lights (Attention, Ready) 2-line |
Software |
Meegeleverde software | Toolbox FX configuration utility SNP alerts and installation software on CD-ROM Print driver (HP PCL 6) |
Beeldscherm |
Beeldscherm | LED |
Poorten & interfaces |
Aansluitingen | 1 Ethernet 1 Hi-Speed USB 2.0 |
Design |
Elektromagnetische compatibiliteit | CISPR 22: 2005/EN 55022: 2006 Class B, EN 61000-3-2: 2006, EN 61000-3-3: 1995+A1+A2, EN 55024: 1998+A1+A2, FCC Title 47 CFR, Part 15 Class A (USA), ICES-003, Issue 4, (Canada), GB9254-1998, EMC Directive 2004/108/EC with CE Marking (Europe), other EMC approvals as required by individual countries |
